Description¶
MY-AQ1
Advanced Environmental Monitoring Device
Leleka is a state-of-the-art environmental monitoring device designed to provide precise, real-time data on air quality, light levels, and atmospheric conditions. Equipped with high-end sensors — Leleka delivers comprehensive insights into your surroundings. Whether for smart homes, offices, or industrial applications, Leleka ensures optimal environmental conditions with unmatched accuracy.
All images and trademarks are the property of their respective owners.
This device is not certified for any of the protocols or systems shown above.
Compatibility is based on adherence to open standards and is provided for informational purposes only.
No affiliation or endorsement by the protocol owners is implied.
This device is not certified for any of the protocols or systems shown above.
Compatibility is based on adherence to open standards and is provided for informational purposes only.
No affiliation or endorsement by the protocol owners is implied.
Question
Links to official stores will be provided here.
Specs¶
| Feature | Value/Description |
|---|---|
| CPU | ESP32-C6-MINI-1, 32-bit RISC-V, 4 MB Flash |
| Sensors | CO₂, VOC, Illuminance, Temperature, Humidity, Pressure |
| LED | 1× RGB (WS2812), adjustable brightness, night mode |
| Button | 1× multifunctional |
| Connectivity | Web UI, MQTT, HomeKit, Zigbee (simultaneously) |
| Autonomous Mode | Wi-Fi AP, local data access |
| Alerts | Buzzer, Telegram, Discord, HTTP(S) GET/POST |
| Direct Binding | Zigbee On/Off clusters |
| Power Supply | 5V USB-C |
| Parameter | Model | Manufacturer | Range / Accuracy |
|---|---|---|---|
| CO₂ | SCD40 | Sensirion 🇨🇭 | 400–2000 ppm, ±(50 ppm + 5%) |
| VOC | SGP40 | Sensirion 🇨🇭 | VOC index 0–500, ±15% |
| Illuminance | BH1750 | Rohm 🇯🇵 | 1–65,535 lx, ±20% |
| Temperature | SHT31 | Sensirion 🇨🇭 | 0…90 °C, ±0.2 °C |
| Humidity | SHT31 | Sensirion 🇨🇭 | 0–100 % RH, ±2% RH |
| Pressure | BMP280 | Bosch 🇩🇪 | 300–1100 hPa, ±1 hPa |
